Today, most of the metal products are produced in the form of steel sheets, and each type of steel sheet is used for specific purposes. Steel sheet consists of different materials, each of which is used in different parts of the industry and construction of buildings.

Today, all kinds of steel sheets are produced in different factories, such as Mobarake steel in Isfahan, Aksin steel and Kavian steel in Ahvaz, and Gilan steel. Steel sheet or iron sheet is one of the most widely used steel products, which is available in different alloys, sizes and thicknesses. There are.. These sheets are made of ordinary steel or alloy steel and are produced by cold and hot rolling methods, and the most common ones include black, oil, galvanized, colored, stainless steel, etc. Metal sheets have different uses depending on their various characteristics and properties. The price of steel sheets is also influenced by the material of the sheet, its thickness, the manufacturing plant and the method of production.

Types of metal sheets

black sheet

oiled sheet

Ribbed sheet

Galvanized sheet

Steel sheet

copper sheet

color sheet

Shutter sheet

1- Black sheet

Among the types of steel sheets, black sheet is one of the most widely used products. It should be noted that the name black sheet is just a term in the country’s steel market, and there is no mention of black color on this sheet, and because this sheet is not shiny and polished, it is called black sheet.

The black metal sheet is produced using the hot rolling method, in such a way that the steel ingot is heated to a temperature before melting until it becomes a paste, in the next step, it enters the rolling process and is slowly widened and flattened in such a way that the shape of a rectangular cube with length during this process, due to the high temperature of the ingot, the path of the process is cooled with water, and after each rolling step, the output product of each step enters the furnace again to reach the appropriate temperature. In each step, the distance between the rollers is reduced to the extent that in the last step, the distance between the rollers reaches the thickness of the sheet. Factories such as Mobarakeh Steel Factory, Kavian Steel, Axin Ahvaz and Saba Steel are active in the production of this product.

2-Oil sheet

 Like black sheet, the name of oiled sheet has nothing to do with the oiliness of the surface of this type of sheet, but because of the polished and shiny surface of this type of sheet in the market, it is called oily. The production process of oiled sheets is done by cold rolling method and for this reason this product has a shiny surface. The purpose of producing this type of sheet is to achieve high surface quality and to prepare sheets with lower thicknesses

The oil sheet production method is such that the output product of the hot rolling process (after cooling) enters the acid washing process, and after this process is finished, the sheet is oiled and coiled again.

3- Ribbed sheet

Ribbed sheet is a type of steel sheet that has geometric ridges on its surface with a specific order and order. Since the steel sheets are generally smooth and flat, it is not possible to move or place other objects on them, and any object on them simply slips, for this purpose and with the aim of providing the possibility of movement on the steel surfaces of the sheets. Ribbed are produced

Ribbed sheets can be made from black sheets and oil sheets (according to the place of use). One of the methods of producing corrugated sheet is that after completing the process, the sheet is fed into the treading machine.

4-Galvanized sheet

 Since the corrosion and rusting of steel sheets is always a factor of concern and on the other hand, the production of stainless and corrosion-resistant steel sheets is not economical for industrial use, so galvanized sheets have been produced and manufactured.

There are various methods for coating steel sheets, but galvanizing the sheets is the most economical method possible. For the production of galvanized sheet, oiled sheet is used, and the working method is to immerse the oiled sheet in a bath of molten zinc so that according to the desired thickness of the zinc metal, it is placed on the surface of the sheet.

One of the advantages of galvanized sheets is resistance to corrosion in acidic and humid environments, and these sheets do not suffer from corrosion and damage due to surface scratches (as much as the thickness of zinc).

5-Steel sheet

 Steel sheet is a type of steel sheet that has mechanical properties due to the alloy used in it. This type of sheet has different properties such as rustproof, recyclable and high hardness and strength. There are different elements in the steel sheet, the percentage of which is used in this sheet is different

These elements will create mechanical-thermal properties, hammerability and also increase corrosion resistance. The noteworthy point is that steel sheet is not produced in our country and usually countries like China, Taiwan and South Africa are the countries that produce this sheet.

The most important feature of these sheets is that they are rustproof. One of the components of steel sheet is chromium, and when it combines with oxygen in the air, a layer of chromium oxide is formed on the sheet, and this prevents the sheet from rusting. Among other important features of steel sheet, he pointed out that it can be recycled, and that it has a high degree of hardness and strength of the sheet

6-Copper sheet

 Copper sheets without adding any other elements have high electrical conductivity and therefore are widely used in making conductive parts. In addition to this feature, copper sheets have high fatigue and corrosion resistance, which makes them durable and strong products.

7- Colored paper

 Cold galvanized steel sheet can be polished using sandpaper after the end of this process, then they can be brushed with special rollers and finally another anti-rust coating can be added to them. Painting the cold steel sheet increases its resistance to corrosion and rust.

8= shutter sheet

 Shutter sheet is one of the types of construction sheets and a type of corrugated sheet. This sheet is a kind of thin iron sheet formed by forming metal sheets, especially colored galvanized sheets. In terms of appearance and forming, this sheet is similar to the wave and sinusoidal design of shutter metal sheet in different types and colors and is produced and sold in the market. Each of them has different industrial and construction applications

But it is mostly used in sloping roofs.
